50W 100W Flying Fiber Laser Marking Machine For Stainless Steel / Medical Devices
Contact me for free samples and coupons.
WhatsAPP:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Laser Coder For Metal | Product ID | CL400B |
|---|---|---|---|
| Product Tags | Fiber Fly Laser Marking | Laser Power | 50W,100W |
| Marking Speed | ≤12000mm/s | Laser Wavelength | 10.6um |
| Marking Range | 110X110mm(Standard) Optional:150X150mm,300X300mm | ||
| Highlight | 50W Flying Fiber Laser Marking Machine,100W Flying Fiber Laser Marking Machine,100W Stainless Steel Laser Marking Machine |
||
Product Description
Fiber Laser Marking for Stainless Steel for Medical Devices and Aerospace Part Marking
Fly fiber Laser Marking machine is use for mark on electronic cable, expiry date on plastic , expiry date on rubber, expiry date on metal can,
expriy date on foil pouch bag.
Stainless steel is a metal commonly used for the medical device and aerospace industries. It is anti-corrosive, tolerant to high temperatures,
and has a high tensile strengthSince laser markers make stainless steel marking much easier than other marking methods, both industries rely heavily on laser marking
to add traceability and identification marks on their stainless steel parts.
The hardness of stainless steel can make it difficult to mark without a laser. Additionally, some marking methods, like chemical etching,
can cause the steel to lose its anti-corrosive layer.
Laser marking metal targets only the precise area so that you can mark stainless steel without any adverse effects.
With laser markers, you can also mark with an anneal style mark which gives contrast on stainless steel while keeping the anti-corrosive layer intact.
Parameter:
|
project |
Parametertable |
50W |
100W |
|
characteristic |
Machine material |
All aluminum sandblasting oxidation |
|
|
Laser |
The service life is more than 100000 hours |
||
|
Laser wavelength |
1064nm |
||
|
output power |
≥54W |
≥110W |
|
|
Marking speed |
≤12000mm/s |
||
|
controller |
10.2 inch touch controller |
||
|
Cooling system |
Air cooling |
||
|
parameter |
Focus lens |
165mm |
|
|
Minimum linewidth |
0.012mm |
||
|
Repetitionaccuracy |
0.003mm |
||
|
Marking range |
110mm*110mm(optinal) |
||
|
Positioning mode |
Blue light indication |
||
|
Number of rows |
Any line within the marking range |
||
|
Production line speed |
0~130m/min (depending on the material) |
||
|
Software |
Multilingual |
English, Spanish, German, Chinese, Russian, Arabic, etc |
|
|
jurisdiction |
Multi user management authority |
||
|
operating system |
Linuxsystem |
||
|
Inkjet mode |
Static, analog, encoder |
||
|
Reserved signal |
Start, print status, finish, fault |
||
|
data protection |
With power failure data protection energy |
||
|
monitor |
Provide overspeed alarm function |
||
|
De crossing |
Automatic removal of intersections |
||
|
Coding software |
Single and double machine code sending |
||
|
Support type |
typeface |
Chinese and English, numbers, traditional, etc |
|
|
file format |
BMP/DXF/HPGL/JPEG/PLT |
||
|
bar code |
CODE39,CODE128,CODE126,QR |
||
|
Servicing parameters |
Power Supply |
220V/50HZ |
|
|
Power consumption |
600W |
||
|
Net weight of machine |
38kg |
||
|
Overall dimension |
530mmX140mmX165mm |
||
|
environment |
requirement |
External temperature0℃－45℃;humidity≤95 |
|
