20W -100W Handheld Laser Marking Machine Portable Laser Coder Machine
Contact me for free samples and coupons.
WhatsAPP:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Portable Laser Marking | Product ID | CL800A |
|---|---|---|---|
| Product Tags | Fiber Laser Marking Machine | Laser Power | 20W/30W/50W/100W |
| Laser Life | ＞100,000 Hours | Power Supply | 90V~240V 50/60HZ |
| Power Consumption | 300-500W | Marking Range | 75X75mm(Standard) |
| Optional | 150X150mm,300X300mm | ||
| Highlight | 20W Handheld Laser Marking Machine,100W Handheld Laser Marking Machine,Portable Laser Coder Machine |
||
Product Description
20W -100W Handheld Laser Marking Machine Portable Laser Coder Machine
Product Specifications
| Material | Portable Laser marking |
| Product ID | CL800A |
| Product Tags | Fiber Laser Marking Machine |
| Laser Power | 20W/30W/50W/100W |
| Laser Life | ＞100,000 hours |
| Power Supply | 90V~240V 50/60HZ |
| Power consumption | 300-500W |
| Marking Range | 75X75mm(Standard) |
| Optional | 150X150mm,300X300mm |
Product Description
The Portable Handheld Fiber Laser Marking Machine is an intelligent system designed for industrial applications including marking on oil/gas pipelines, firearms, nameplates, plastic/rubber parts, and seals. Featuring wireless connectivity via WIFI/Bluetooth/USB/APP for remote control, this lightweight solution is ideal for IoT asset management.
Key Features
- High-precision 2D scanning head with laser etching completed within 20s
- Compact design (≤6kg total weight, 0.8kg marking head) for portability
- Intuitive touch screen operation with red light preview and one-key marking
- Supports multiple barcode types including QR, CODE128, and Data Matrix
- Emergency stop function with material detection software for safety
- Rechargeable battery provides 4 hours working time (8 hours standby)
- Optional carrying solutions: dual shoulder straps or rolling luggage
- Remote control capability via Wi-Fi, Bluetooth, and USB connections
Technical Parameters
| Parameter | 20W | 30W |
|---|---|---|
| Machine Material | All aluminum sandblasting oxidation | |
| Laser Wavelength | 1064nm | |
| Output Power | ≥23W | ≥34W |
| Marking Speed | ≤12000mm/s | |
| Controller | 10.2 inch touch controller | |
| Minimum Line Width | 0.012mm | |
| Marking Range | 110mm*110mm (optional) | |
| Power Supply | 220V/50HZ | |
| Net Weight | 8kg | |
| Operating Environment | 0℃－45℃; humidity ≤95% | |
